• Model NO.：GJB
• Name and Description：Food Grade Stage Piston Stainless Steel Pressure
• Homogenizer Appication：Milk , Juice, Beverage, Butter, Honey, Cream
• OEM：Yes
• Processing Pressure：25~100MPa
• Motor Power：5.5-110kw
• Flow Ralte：500~10000L,H
• Certificate：Ce
• Voltage：380V50Hz 3phase
• Homogenizer Pressure：Two Stage
• Homogenizer Working Life：More Than 10 Years
• Packing：Wooden Box
• Delivery：10 Days After Get Your Reply .
• Material：Stainless Steel 304 ,316 ,316L
• Motor：Siemens ,ABB,China Brand
• MOQ：1sets
• Transport Package：Standard Wooden Box
• Specification：CE
• Trademark：KAIQUAN
• Origin：Shanghai, China
• HS Code：8479820090
• Production Capacity：100 Units,Month

Basic Info.

Model NO. GJB Name and Description Food Grade Stage Piston Stainless Steel Pressure Homogenizer Appication Milk , Juice, Beverage, Butter, Honey, Cream OEM Yes Processing Pressure 25~100MPa Motor Power 5.5-110kw Flow Ralte 500~10000L/H Certificate Ce Voltage 380V50Hz 3phase Homogenizer Pressure Two Stage Homogenizer Working Life More Than 10 Years Packing Wooden Box Delivery 10 Days After Get Your Reply . Material Stainless Steel 304 /316 /316L Motor Siemens ,ABB,China Brand MOQ 1sets Transport Package Standard Wooden Box Specification CE Trademark KAIQUAN Origin Shanghai, China HS Code 8479820090 Production Capacity 100 Units/Month

Product Description

Food Grade Stage Piston Stainless Steel Pressure Piston Homogenizer For Factory
Yogurt Homogenizer Ice Cream Homogenizer Paste Homogenizer Honey Homogenizer
GTB high pressure homogenizer pump series is the kind of equipment which can homogenize the liquid material and make it become high-pressure spray. The high pressure homogenizer pump reciprocates the pump position, high press the liquid, fully mixed and refined the material.



The high pressure homogenizer can use to homogenize the dairy product material in high pressure, refine the fat globule, prevent or decrease the stratifying of the liquid material; Make the product much more nicety, to prove the quality of the product.

The high pressure homogenizer pump also the important equipment of the powder manufacture. (Such as pharmaceutical industry, chemical industry, etc. )

Do not use the product to handling the suspending liquid or the high viscosity liquid. (viscosity less than 0.2 PA. S)
GJB high pressure homogenizer
Milk High Pressure Homogenizer, You Can Buy Various High QualityMilk High Pressure Homogenizer Products from us,  the 250bar milk homogenizer,

CE CERTIFICATED HOMOGENIZER FOR MILK, JUICE, DAIRY, ICECREAM, SOYBEAN MILK, HONEY
Soybean milk homogenizer,  40MPA homogenizer
Tea drinks homogenizer,  juice homogenizer
homogenizer pumps
High pressure homogenization is a standard industrial process for dairy products, to improve their stability and shelf life

Model No. Technical parameter	KQ0.5-25	KQ1-25	KQ1.5-25	KQ2-25	KQ2.5-25	GJB3000-25 KQ3-25	KQ5-25
Rated pressure(MPa)	25	25	25	25	25	25	25
Rated flow ( Liters/H )	500	1000	1500	2000	2500	3000	5000
Medium temperature(C)	≤85	≤85	≤85	≤85	≤85	≤85	≤85
Feeding pipe diameter(mm)	25	25	25	25	25	32	40
Discharge pipe diameter(mm)	15	15	20	20	20	20	25
Power of motor(Kw)	5.5	7.5	11	15	18.5	22	45
Volt and Electricity Flow	220V,60HZ,3PH	380V,50HZ	380V,50HZ	380V,50HZ	220V,60HZ,3PH	380V,50HZ	380V,50HZ
Outline dimension (m) Length * width * height	1.16×0.9×1.24	1.16×0.9×1.24	1.16×0.9×1.24	1.4×1.1×1.42	1.4×1.1×1.42	1.4×1.1×1.42	2.2×1.45×1.1
Weight(Tons)	0.4	0.5	1.25	1.25	1.25	1.25	1.7

Food Grade Stage Piston Stainless Steel Pressure Piston Homogenizer For Factory .
