• Model NO.：RG200
• Cooking Pot Structure：Double Layer Made of Stainless Steel
• Agitator：with , Without Agitator, Customized
• Cooking Method：Nature Gas , LGP
• Way of Discharge：Drainage From Bottom , Tiltable
• Construction Material：Ss304 , Ss316
• Certificate：CE
• Transport Package：Wooden Case
• Specification：CE ISO
• Origin：Wenzhou China

Basic Info.

Model NO. RG200 Cooking Pot Structure Double Layer Made of Stainless Steel Agitator with / Without Agitator, Customized Cooking Method Nature Gas / LGP Way of Discharge Drainage From Bottom / Tiltable Construction Material Ss304 / Ss316 Certificate CE Transport Package Wooden Case Specification CE ISO Origin Wenzhou China

Product Description

Stainless steel gas heating soup boiler
1. Soup boiler made of stainless steel
2. Soup boiler with customized cooking capacity
3. Gas heating, nature gas or LGP
4. Automatic control temperature and gas

Soup boiler / Jacketed kettle / jacketed pot / cooking kettle
Soup boiler is a kind of cooking and mixing device used in dairy processing and beverage production.
You can produce tomato paste, puree, milk, and many other products by jacketed cooking kettle.
Also, you can make soup by our cooking kettles or cooking pan.

Soup boiler can be heated by gas. Wenzhou wanyuan food machinery produce gas jacketed kettle in different capacity. We have nature gas heating type cooking kettle, also we produce LGP heating cooking vat or kettle according to customer request.

Gas heating Soup boiler can be tilting type, or tri-leg mounted. There are not too much different between tri-leg mounted gas cooking kettle and tilting Soup boiler, the only difference is: They use different kind of drainage method.
Tilting Soup boiler use gear device to turn the Soup boiler over when discharge while tri-leg Soup boiler <or vertical jacketed kettle> equipped with a drainage pipe at the jacketed pot <jacketed pan or jacketed vat> bottom.

Gas heating soup boiler pictures:



Want to know more about our automatic control gas cooking kettle?
Please send us your detail reqeust.

Wenzhou wanyuan food machinery factory- Jacketed kettle / jacketed pot / cooking kettle
Here below is our gas heating soup boiler/jacketed kettle specification

Specification for gas heating jacketed kettle

Model	Heating Area (m²)	Conduction Oil (kg)	Blending Rate (r/min)	Boiling Time (min)
RG50	0.45	20	35	10~15
RG100	0.58	30	35	10~15
RG150	0.88	45	35	20~30
RG200	1.13	55	35	20~30
RG300	1.43	65	35	20~30
RG400	1.75	75	35	20~30
RG500	2.00	120	35	20~35
RG600	2.30	160	35	20~35
