• Model NO.：GD300T
• HS Code：84382000

Basic Info.

Model NO. GD300T HS Code 84382000

Product Description

Automatic hard candy depositing line (PLC controlled)

GD150/300/450/600 hard candy depositing line is a compact unit which can continuously produce various kinds of hard candies under a strict sanitary condition. It is also an ideal equipment which can produce out good quality products with the saving of both the manpower and the space occupied.


The strong point of the line is as following:
1. PLC /computer process control available;
2. An LED touch panel for easy operating;
3. The standard production capacity from 150 kgs/h to 450kgs/h;
4. The main parts is made of hygienic stainless steel;
5. Optional (mass) flowing controlled by Frequency inverters;
6. In-line injection, dosing and pre-mixing techniques for the proportional addition of liquid(milk); Dosing pumps for the automatic injection of colors, flavors and acids;
7. One set of extra chocolate paste injection system for making chocolate-central candies; "two/three-color striped depositing", "two or three color double layers depositing", "central filling", "clear" hard candies and etc. Can be made.
8. Moulds can be made according to the candies samples provided by the customer. "

ADVANTAGES:
1) Reliability, easy cleaning and maintenance
2) Accurate filling and simple changeover.
3) Servo-controlled accurate movement
4) Automatic belt tensioning










John liu

Shanghai TARGET INDUSTRY Co., Ltd. HD
Office: RM609, No. 11 Blding, ZhuoYue Center, Lane 388, Baifu Road, Fengxian, Shanghai, 201400
Factory Add (SHINWEI): NO. 7151, Puwei Road, Fengxian, Shanghai, China 201417


Model	GD150	GD300	GD450	GD600
Output(kg/h)	150	300	450	600
Max candy weight	6g	6g	6g	6g
speed	55~65 n/min	55~65 n/min	55~65 n/min	55~65 n/min
Steam consumption Steam pressure	250kg/h, 0.5~0.8MPa	300kg/h, 0.5~0.8MPa	400kg/h, 0.5~0.8MPa	500kg/h, 0.5~0.8MPa
Compressed air consumption Compressed air pressure	0.2m3/min, 0.4~0.6MPa	0.2m3/min, 0.4~0.6MPa	0.25m3/min, 0.4~0.6MPa	0.25m3/min, 0.4~0.6MPa
Electric power needed	18kW/380V	27kW/380V	34kW/380V	42kW/380V
Total length(m)	15	17	17	20
Gross weight	3500kg	4000kg	4500kg	5000kg
