• Name：Potato Chips Machine Production Line
• Function：Making Fresh Potato Chips
• Final Products：Fired Potato Chips
• Type：Fully Automatic
• Material：Stainless Steel
• Capacity：200,500,1000,2000kg,H
• Transport Package：Wooden Box
• Specification：3600
• Origin：China
• Production Capacity：100,500,1000,2000kg,H

Lift feeding machine(1) Purpose: Lift the potato raw materials into the peeling machine for peeling treatment.
(2) Features: stainless steel frame structure, easy to maintain, easy to clean, no rust.
(3)Dimensions: 2500*630*1650mm
Power: 0.55kw /380v/ 50Hz
Effective width of conveyor belt: 500 mm




Brush cleaning peeling machine(1) Purpose: Wash and peel potatoes.
(2) Features: Spiral discharge realizes continuous production, imported nylon silk wool roller, durable, stainless steel frame structure.
(3)Dimensions: 2600*850*1650mm
Hair roller length: 1.8 meters
Power: 4.55kw /380v/ 50Hz
Number of hair rollers: 9





Picking line(1) Purpose: Manually select potatoes that have been cleaned and peeled to remove unclean areas and unqualified materials.
(2) Features: stable operation, stainless steel frame structure, easy maintenance and easy cleaning.
(3)Dimensions: 4000*730*780mm
Power: 1.5kw /380v/ 50Hz
Effective width of conveyor belt: 500 mm




Imported cutting machine(1) Purpose: Cut potatoes after washing and peeling.
(2) Features: Originally imported from Taiwan, the blade is durable and runs smoothly. After cutting the strips, it directly enters the rinsing machine for rinsing treatment.
(3)Dimensions: 1070*560*900mm
Power: 1.5kw /380v/ 50Hz
Cutting size: 7-10mm
Output: 200-300kg/h




Immersion lifting machine(1) Purpose: Rinse the cut potatoes to remove the starch on the surface.
(2) Features: After cutting the strips into the water to prevent the adhesion of the French fries, the stainless steel chain mesh belt conveys.
(3)Dimensions: 2500*1000*950mm
Total power: 0.55kw /380v/ 50Hz
Effective width of conveyor belt: 800 mm





Hair roller cleaning machine(1) Purpose: To remove impurities from the cleaned French fries, remove broken pieces and leftovers, etc.
(2) Features: It has a conveying function and uses a wool roller to remove impurities.
(3) Technical parameters: 2500*1000*1350mm
(4) Total power: 1.5kw/380v/50hz
(5) Width of wool roller: 800mm




Blanching machine(1) Purpose: Use hot water at 60-95°C to blanch French fries to remove starch and protect color.
(2) Features: Adopt gas heating, with integral lifting function, easy to clean, maintain and clean.
(3)Dimensions: 3500*1150*2020mm
Power: 83.55kw /380v/ 50Hz
Transmission: 1.5kw
Circulating water pump: 1.5kw
Increase: 0.55kw
Electric heating power: 80kw
Effective width of conveyor belt: 800 mm




Air-cooled dehydration machine(1) Purpose: Remove excess water on the surface of French fries after blanching, and shorten the subsequent frying time.
(2) Features: Equipped with 4 snail fans, the air nozzle is like a wind knife, so that the moisture of the material French fries can be blown away or evaporated in a short time, effectively preventing the oily phenomenon during frying and shortening the frying time.
(3)Dimensions: 4000*950*1600mm
Power: 3.75kw /380v/ 50Hz
Transmission: 0.75kw
Fan: 0.75*4 units
Effective width of conveyor belt: 800 mm




Frying line(1) Purpose: Fry the cooled French fries.
(2) Features: using gas heating, with oil storage tank, with coarse filter, with exhaust hood, fried French fries, temperature 0-220ºC adjustable, frying time frequency conversion speed,
(3) Dimensions: 3000*1160*2200mm
Total power: 123.55kw /380v/ 50Hz
Transmission power: 1.5kw, oil pump: 1.5kw
Boost power: 0.55kw
Electric heating power: 120kw
Effective width of conveyor belt: 800 mm




Vibration oil drain machine(1) Dimensions: 2000x1450x800mm,
(2) Equipment material: stainless steel
(3) Power: 0.26kw/380v/50hz
(4) Features: The equipment uses stainless steel punching, the punching distance is 2-3mm, and the fries after frying are flattened by vibration, while removing excess oil on the surface.




Air-cooled deoiling machine(1) Purpose: Remove excess oil on the surface of banana slices after frying, and at the same time, it can quickly cool down.
(2) Features: The equipment is equipped with an oil pan. The oil that has been blown off can be collected and reused through the oil pan. This saves oil and makes the banana slices taste better without greasy and convenient storage.
(3)Dimensions: 4000*950*1600mm
Total power: 3.75kw /380v/ 50Hz
Transmission: 0.75kw
Fan: 0.75*4 units
Effective width of conveyor belt: 800 mm




Packaging & Shipping

1. Packaging:

Packed by standard import & export wooden cases or carton boxes.

2. Shipping:

By logistics; by automobile; by train; by shipping; by air etc.

Company Information



Our Services

1.We have more than15 years manufacture and export experience.
2.Exporting to all over the world,win high reputation among customers.
3.CE, ISO 9001 and Strict Production Guideline to guarantee the high quality of our products.
4.Near the Qingdao port convenient for exporting.
5.Customer service staff 24 hours online,offer free technical support.
6.Factory and Competitive Price we offer.
7.Strong Research & Development technical team.
8.Various machinery to meet all your needs at our factory.
9.Engineers are available to guide the installation and take care of other problems.
10.We offer OEM&ODM service to meet all your requirements.

FAQ

1.Q:Are you trading company or manufacturer?
A:We are original equipment manufacturer.
2.Q:How long is your delivery time?
A:It is according to the model and quantity.Generally it is 3-5 days if the product are in stock.It will be 15-30 days if you want to customize the product.
3.Q:Do you provide samples? ls it free or extra?
A:Yes,we could offer you the sample.But it's not free.
You need to pay for the sample and the cost of freight.
4.Q:What is your terms of payment?
A:We accept T/T,Westerm Union,Money Gram,Paypal,etc.
Payment
