Clj Manufacture Mnsw30df Horizontal Emery-Roller Rice Whitener Machine
HUNAN CHENZHOU GRAIN & OIL MACHINERY CO., LTD.- Type：Rice Mill
- Voltage：380V
- Appearance：Horizontal
- Press Materials：Rice
- Condition：New
Base Info
- Model NO.：MNSW30DF
- HS Code：8437800000
- Production Capacity：2-8.5t,H
Description
25Screen wide 8 Feeding dail 17 Shaft base for feeding Screen narrow 9 Fixed deck support 18 Bearing 6226
2.4. Noise Condition
Operation noise of the whole machine is less than 85 decibels.
Chapter III Installation
3.1. Handing and Installation Safety Matters
3.1.1 When handling, please select appropriate lifting tool according to equipment lifting location plan and equipment weight to prevent personnel injury or equipment damage.
3.1.2 Pay special attention to the lifting position and direction of the main body of equipment.
3.1.3 Equipments are not allowed to stack.
3.1.4 Choose appropriate installation position according to installation location drawing; pour
appropriate concrete foundation according to the total weight of equipments.
3.1.5 Lift in strict accordance with lifting chart; find out the position of the center of the gravity and lift levelly; it is not allowed to lift unevenly on front, back, left and right so as to prevent equipment rollover that may result in personnel or equipment damage.
3.1.6 During the lifting, no person is allowed to stand under lifting machine and equipment in order to avoid the accident of endangering the safety of personnel.
3.1.7 Please do not operate of the equipment is damaged or missing parts.
3.1.8 Do not place heavy objects on the equipment.
3.1.9 After concrete foundation is solid, place 8 sizing block on the foundation according to the installation diagram; place the device smoothly on the sizing block and adjust the equipment level through the sizing block.
3.2. Handling and Installation Procedures
3.2.1. Select Appropriate Handling Equipment
The following guidelines should be strictly followed to lift the equipment properly and safe
Use equipment with sufficient lifting capacity;
Wrap all sharp edges;
Check the safety devices attached at lifting hook;
Do not move the load before effective lifting;
Pay special attention to the lifting position and direction of the main body of equipment.
3.2.2. The work before lifting
Make sure the security clamp to fix the sieve ship and frame have been properly installed before lifting;
Ensure that all personnel are safety away from the equipment;
Make sure the load does not swing after being lifted;
Make sure all parts that may fall are safely positioned;
Lift vertically to prevent the collision with nearby objects.
3.2.3. Move
Always use rod, lever and hook to lift and move equipments and never use hand.
The person responsible for moving and lifting should
Know the destination of equipment hanging and shifting clearly;
Stand at the position which can be easily viewed by crane operator when directing;
Stop the operation immediately if dangerous situation occurs (e.g. someone passes by)
3.2.4. Place machine
Before the machine is put in place properly, make sure that the ground is level and has sufficient strength to support the equipment. The machine shall not be placed near the following locations.
3.3. Service environment
3.3.1 The equipment shall be used in the following environment conditions.
Environment
Ambient Temperature -100C~450C(non- icing)
Ambient Humidity 90%RH Below (non-condensing) Storage Temperature -200C~+650C Environment Indoor (no corrosive gas, flammable gas, oil mist, etc.) Altitude Any Altitude
3.3.2 The former approach must has complete cleaning, destine, magnetic separation, husking and paddy separation. The impurities, stones, metals mustn't enter in the whitening chamber in case any damage to the machine.
3.4. Installation method
3.4.1 Installation of main body
a)Put the machine on required the place, fix the machine by 6 foundation bolt M16, check if the machine is level, if not use spacer to leveling and tighten the bolts avoiding the noise. See the pic below
b)To make it easy to move and exchange parts, leave enough space(especially leave space for exchange main axle and bearing).
3.4.2 Installation of electric control
a)Put the electric box at appropriate position, close to the main body. Connecting the wires by present regulation.
b)Use 16mm2 copper wire.
c)The motor must under protection of overload and low-voltage, with reduction voltage starting.
d)Equipped with starting, stop switch and ampere meter. Specific value is 150:5(when use 37kw motor) and 100:5(use 30kw motor). Please choose current transformer accordingly.
e)Working time counter is recommended to maintenance timely.
DANGER Mustn't use worn wires.
Electric leakage can cause damage to goods and personnel
3.4.3 Chute installation should be workable, easy to maintenance and beautiful.
3.4.4 Installation of air net for bran collecting
Air blower 9-26NO-4.5A is recommended, the air net installation is suggested as follow
3.5 Checking power source
3.5.1 before connecting, make sure the voltage of machine is same with power source
3.5.2 after connecting wires, make sure it on correct connector
3.5.3 machine must has ground connection to avoid electric shock
3.5.4 this action must be done by qualified electrician
Chapter IV Operation
4.1. Operating position
4.2. Preparation before Switching on: the follow steps must be taken especially before the first starting
4.2.1 Machine must be installed and connected according to the regulation.
4.2.2 Check whether the bolts and nuts are tightened up and whether the tension and parallelism of V-belt are proper.
4.2.3 Check whether the opening and closing adjustment of feed hopper and pressure door is flexible.
4.2.4 Check is the rotate direction of motor if correct ( faced with feeding port, the correct direction is clockwise).
4.2.5 checking if there is below situation when running without material
a) the temperature of bearings must be lower than 30ºC
b) If there is abnormal noise or vibration
c) If the electric current is normal
d) Check if there is vibration at ground, if yes, leveling each foot by iron rod.
4.2.6 Adjustment of air volume
When running, the air suction volume should be about 2000m3/h in order to clean all bran.
4.3 Start and shut down
Start: start the posterior host--------start main machine-------running without material(test run)----------open feeding board--------adjusting flow------adjusting pressure gate
When working, don't put anything on the machine.
Shut down: stop posterior host-------close feeding board---------open pressure gate-------shut the power-------open access door-------clean
4.4 Operation
4.4.1 Adjustment of feeding flow
If test-run is normal, put the pressure lump at the bottom, open the feeding board, fill the whitening chamber with material. When it starts to outletting stabilize the electric current and adjusting the flow, observing the ampere meter. Adjusting the whitening degree according to the rated current.
Notice: the actual current can't over rated current and it can't run full load too long.
4.4.2 Adjustment of whitening degree and broken rate
Usually, whitening degree is in direct proportion to broken rate, high whitening degree then more broken; low then less broken. After start the machine, when current is stable, whitening degree can be changed by adjusting the pressure lump.
Whitening degree also can be changed by adjusting the mobile blade, but this action must be done when the machine stops and the blade can above the screen for 1.5mm at most.
4.4.3 Adjustment of tightness of belt
To adjusting the tightness of belt by changing the position of motor plate.
Chapter V Maintenance
5.1. Maintenance
5.1.1.Check fastening of bolts and tension of belts regularly.
5.1.2.Regularly replace lubricating oil and grease.
5.1.3. The outlet, Bran suction chamber, feed chute and Bran Suction pipe are places which accumulate bran and should be cleaned periodically.
5.1.4. Regularly check the following items
Caution Maintenance and examination should be conducted only after the machine stops completely. (The spindle may run further for about 3 minutes after switching off the machine.)
5.2. Replacement Sequence of easily worn Parts
5.2.1. Procedure of replacing sieve
Unscrew M10 bolt on the mobile deck support,
When exchange new sieve, please remove the grease.
5.2.2 Changing screw and emery roller
a)Open the access door on both sides, take away mobile deck support, remove the sieve.
b)Disassemble the locknut and lock washer.
c)Unscrew 6 screws M16, and remove the outlet bearing base by 2 threaded rods with length over 60mm.
d) Take away axle sleeve, feeding dial, emery roller and screw and install new ones.
5.2.4 Notice when reinstall
a),Don't forget flat key when install screw and emery roller, and notice the installing order.
b),If there is blur between rollers, roller and screw, should remove the blur. The connecting point of each part should be smooth to avoid broken.
c),When replace parts of whitening chamber, must remove the blur that might cause broken.
5.3 Machine lubrication
5.3.1 Cycle
The lubrication of machine shall be carried out by fixed staff on a regular basis; the maintenance may be conducted at the production gap; it is required to lubricate the bearings every six months.
5.3.2 Lubricant product
Use the generic lithium-based grease; do not mix different types of lubricants to use after having chosen a certain type of lubricant, because this will reduce the service life of related components and affect the normal operation.
5.4 Check the tightness of fasteners
5.4.1 Inspection cycle
Check the degree of tightness of bolt and nut. Check one after 8 hours of work, and later fasten all for every 2,000 hours.
5.5 Trouble shooting
2.4. Noise Condition
Operation noise of the whole machine is less than 85 decibels.
Chapter III Installation
3.1. Handing and Installation Safety Matters
3.1.1 When handling, please select appropriate lifting tool according to equipment lifting location plan and equipment weight to prevent personnel injury or equipment damage.
3.1.2 Pay special attention to the lifting position and direction of the main body of equipment.
3.1.3 Equipments are not allowed to stack.
3.1.4 Choose appropriate installation position according to installation location drawing; pour
appropriate concrete foundation according to the total weight of equipments.
3.1.5 Lift in strict accordance with lifting chart; find out the position of the center of the gravity and lift levelly; it is not allowed to lift unevenly on front, back, left and right so as to prevent equipment rollover that may result in personnel or equipment damage.
3.1.6 During the lifting, no person is allowed to stand under lifting machine and equipment in order to avoid the accident of endangering the safety of personnel.
3.1.7 Please do not operate of the equipment is damaged or missing parts.
3.1.8 Do not place heavy objects on the equipment.
3.1.9 After concrete foundation is solid, place 8 sizing block on the foundation according to the installation diagram; place the device smoothly on the sizing block and adjust the equipment level through the sizing block.
3.2. Handling and Installation Procedures
3.2.1. Select Appropriate Handling Equipment
The following guidelines should be strictly followed to lift the equipment properly and safe
Use equipment with sufficient lifting capacity;
Wrap all sharp edges;
Check the safety devices attached at lifting hook;
Do not move the load before effective lifting;
Pay special attention to the lifting position and direction of the main body of equipment.
3.2.2. The work before lifting
Make sure the security clamp to fix the sieve ship and frame have been properly installed before lifting;
Ensure that all personnel are safety away from the equipment;
Make sure the load does not swing after being lifted;
Make sure all parts that may fall are safely positioned;
Lift vertically to prevent the collision with nearby objects.
3.2.3. Move
Always use rod, lever and hook to lift and move equipments and never use hand.
The person responsible for moving and lifting should
Know the destination of equipment hanging and shifting clearly;
Stand at the position which can be easily viewed by crane operator when directing;
Stop the operation immediately if dangerous situation occurs (e.g. someone passes by)
3.2.4. Place machine
Before the machine is put in place properly, make sure that the ground is level and has sufficient strength to support the equipment. The machine shall not be placed near the following locations.
- Exit;
- Fire fighting equipment;
- Access;
- Power line;
3.3. Service environment
3.3.1 The equipment shall be used in the following environment conditions.
Environment
3.3.2 The former approach must has complete cleaning, destine, magnetic separation, husking and paddy separation. The impurities, stones, metals mustn't enter in the whitening chamber in case any damage to the machine.
3.4. Installation method
3.4.1 Installation of main body
a)Put the machine on required the place, fix the machine by 6 foundation bolt M16, check if the machine is level, if not use spacer to leveling and tighten the bolts avoiding the noise. See the pic below
b)To make it easy to move and exchange parts, leave enough space(especially leave space for exchange main axle and bearing).
3.4.2 Installation of electric control
a)Put the electric box at appropriate position, close to the main body. Connecting the wires by present regulation.
b)Use 16mm2 copper wire.
c)The motor must under protection of overload and low-voltage, with reduction voltage starting.
d)Equipped with starting, stop switch and ampere meter. Specific value is 150:5(when use 37kw motor) and 100:5(use 30kw motor). Please choose current transformer accordingly.
e)Working time counter is recommended to maintenance timely.
DANGER Mustn't use worn wires.
Electric leakage can cause damage to goods and personnel
3.4.3 Chute installation should be workable, easy to maintenance and beautiful.
3.4.4 Installation of air net for bran collecting
Air blower 9-26NO-4.5A is recommended, the air net installation is suggested as follow
3.5 Checking power source
3.5.1 before connecting, make sure the voltage of machine is same with power source
3.5.2 after connecting wires, make sure it on correct connector
3.5.3 machine must has ground connection to avoid electric shock
3.5.4 this action must be done by qualified electrician
Chapter IV Operation
4.1. Operating position
4.2. Preparation before Switching on: the follow steps must be taken especially before the first starting
4.2.1 Machine must be installed and connected according to the regulation.
4.2.2 Check whether the bolts and nuts are tightened up and whether the tension and parallelism of V-belt are proper.
4.2.3 Check whether the opening and closing adjustment of feed hopper and pressure door is flexible.
4.2.4 Check is the rotate direction of motor if correct ( faced with feeding port, the correct direction is clockwise).
4.2.5 checking if there is below situation when running without material
a) the temperature of bearings must be lower than 30ºC
b) If there is abnormal noise or vibration
c) If the electric current is normal
d) Check if there is vibration at ground, if yes, leveling each foot by iron rod.
4.2.6 Adjustment of air volume
When running, the air suction volume should be about 2000m3/h in order to clean all bran.
4.3 Start and shut down
Start: start the posterior host--------start main machine-------running without material(test run)----------open feeding board--------adjusting flow------adjusting pressure gate
When working, don't put anything on the machine.
Shut down: stop posterior host-------close feeding board---------open pressure gate-------shut the power-------open access door-------clean
4.4 Operation
4.4.1 Adjustment of feeding flow
If test-run is normal, put the pressure lump at the bottom, open the feeding board, fill the whitening chamber with material. When it starts to outletting stabilize the electric current and adjusting the flow, observing the ampere meter. Adjusting the whitening degree according to the rated current.
Notice: the actual current can't over rated current and it can't run full load too long.
4.4.2 Adjustment of whitening degree and broken rate
Usually, whitening degree is in direct proportion to broken rate, high whitening degree then more broken; low then less broken. After start the machine, when current is stable, whitening degree can be changed by adjusting the pressure lump.
Whitening degree also can be changed by adjusting the mobile blade, but this action must be done when the machine stops and the blade can above the screen for 1.5mm at most.
4.4.3 Adjustment of tightness of belt
To adjusting the tightness of belt by changing the position of motor plate.
Chapter V Maintenance
5.1. Maintenance
5.1.1.Check fastening of bolts and tension of belts regularly.
5.1.2.Regularly replace lubricating oil and grease.
5.1.3. The outlet, Bran suction chamber, feed chute and Bran Suction pipe are places which accumulate bran and should be cleaned periodically.
5.1.4. Regularly check the following items
| Items | Description | Frequency |
| Overheating of Main Bearing | Touch the bearing block to check overheating after running for 10 minutes. When overheating detected, remove and check. Replace it if necessary. | Weekly |
| Abnormal Noise | Run each units separately to exclude abnormal noises before starting. | Anytime |
| V-belt tightness | Press the belt by hand, if it can be pressed down 20mm, the V-belt tightness is appropriate | Weekly |
| Sieve Wearing | Usable unless broken or deformed | Weekly |
| Bran Accumulation inside the machine | Clean interiors | weekly |
| Bran accumulation in the bran pipe | Clean the bran in the bran pipe | Periodically |
5.2. Replacement Sequence of easily worn Parts
5.2.1. Procedure of replacing sieve
Unscrew M10 bolt on the mobile deck support,
When exchange new sieve, please remove the grease.
5.2.2 Changing screw and emery roller
a)Open the access door on both sides, take away mobile deck support, remove the sieve.
b)Disassemble the locknut and lock washer.
c)Unscrew 6 screws M16, and remove the outlet bearing base by 2 threaded rods with length over 60mm.
d) Take away axle sleeve, feeding dial, emery roller and screw and install new ones.
5.2.4 Notice when reinstall
a),Don't forget flat key when install screw and emery roller, and notice the installing order.
b),If there is blur between rollers, roller and screw, should remove the blur. The connecting point of each part should be smooth to avoid broken.
c),When replace parts of whitening chamber, must remove the blur that might cause broken.
5.3 Machine lubrication
5.3.1 Cycle
The lubrication of machine shall be carried out by fixed staff on a regular basis; the maintenance may be conducted at the production gap; it is required to lubricate the bearings every six months.
5.3.2 Lubricant product
Use the generic lithium-based grease; do not mix different types of lubricants to use after having chosen a certain type of lubricant, because this will reduce the service life of related components and affect the normal operation.
5.4 Check the tightness of fasteners
5.4.1 Inspection cycle
Check the degree of tightness of bolt and nut. Check one after 8 hours of work, and later fasten all for every 2,000 hours.
5.5 Trouble shooting
| Fault | Possible Causes | Remedies |
| High percentages of broken | Poor quality of raw materials Screen blade is too thick and the shape edges have not been chamfered There are burrs inside the whitening chamber The rotating speed is too high | Remove sharp edges and burrs Replace motor pulley with small one |
Abnormal Vibration | Fasteners loosing Unbalances caused by uneven wearing of emery roller, Screw thruster or feed dial roller Bearing wearing Supporting points of machine do not touch the ground due to bad foundation level, | Tighten all fasteners Replace new spare parts Replace the bearing Shim and fasten the anchor bolts |
| Poor Precision | Parts wearing in whitening chamber(Emery roller, Screen blade ,etc) Input too much Belt slipping | Replace with spare parts and adjusting Screen blade Adjust the Input Tighten the belt |
