• Processing Material：Natural Ingredients
• Process：Frozen and Chilled
• Main Material：SUS304,SUS316L
• Processing：Beer Fermenting
• Inner Wall Treating：Mirror Polish
• Dimple Jacket Thickness：1.5mm
• Capacity：100L--20000L
• Technology Advantage：PU Insulation, Dimple Jacket, Cooling System Ect
• Function：Wort Fermentation
• Shape：Dished Top and 60 Degree Cone Bottom
• Welding：TIG Welding
• Cooling Jacket：Dimple Cooling Jackt
• Insulation：80mm Polyurethane
• Thickness of Tanks：Inner 3mm,External 2mm
• Washing Way：CIP Spray Ball
• OEM：Accept Customized
• Transport Packag1e：Soft Clothed or Wooden Box
• Transport Package：Wooden Box
• Specification：5800×1050×1850mm(L×W×H)
• Trademark：LAIFU
• Origin：China Zhejiang
• HS Code：7307290000
• Production Capacity：30 Units Per Month

Basic Info.

Processing Material Natural Ingredients Process Frozen and Chilled Main Material SUS304/SUS316L Processing Beer Fermenting Inner Wall Treating Mirror Polish Dimple Jacket Thickness 1.5mm Capacity 100L--20000L Technology Advantage PU Insulation, Dimple Jacket, Cooling System Ect Function Wort Fermentation Shape Dished Top and 60 Degree Cone Bottom Welding TIG Welding Cooling Jacket Dimple Cooling Jackt Insulation 80mm Polyurethane Thickness of Tanks Inner 3mm/External 2mm Washing Way CIP Spray Ball OEM Accept Customized Transport Packag1e Soft Clothed or Wooden Box Transport Package Wooden Box Specification 5800×1050×1850mm(L×W×H) Trademark LAIFU Origin China Zhejiang HS Code 7307290000 Production Capacity 30 Units Per Month

Product Description

We Can Make The Brewing Equipment For Beer, Wine, Sparkling Wine ,Whiskey,Gin, Brandy, Run Etc
The Equipment Capacity From 300l To 30000l.
Beer Equipment: Including The Brewhouse,Fermenter , Brite Tank , Cip Trolley Etc;
Wine Equipment: Including The Red Wine/White Wine/Sparkling Wine Tank , Floating Lid Wine Tank And Whole Wine
Production Line;
Distillation Equipment: Including The Run/Whiskey/Brandy/Gin/Vodka Stills

Fermenter is available from 50L to 50, 000L with an average 25% Head Space. All tank have a Dish top, a Cylinder body and a 60-70° Cone Bottom. Certified stainless steel material for all tanks, with 100% TIG welded (Argon-arc welded) joints and seams with sanitary interior Polish. Dimple Plate jacket for Glycol cooling & high efficient Polyurethane foam insulation. All tanks use Tri-clamp connections, are designed for up to 0.2MPa and tested at 0.4MPa (we own the Manufacture License of Pressurized Vessels). Manway on the side or on the top. CIP cleaning ball and pressure regulating valve are available. We will provide turnkey project and service to meet your brewery's space and height restrictions.

Fermenter Standard Features
Material: 304 Stainless Steel
Interior And Exterior Finish Polished To A Sanitary Finish
Interior Finish Pickled And Passivated
Exterior Brushed, Fully Welded Exterior Shell
60-72 Degree Cone Bottom, With An Average Of 25% Head Space
Rotating Racking Port
Top Manhole Or Side Manhole
Dual Zone Dimple Cooling Jackets
Polyurethane Insulation 80mm
Co2 Blow Off Arm
Cip Arm And Spray Ball
Sanitary Tri-Clamp Connection
Dry Hop Port
Stainless Steel Handle Butterfly Valve,Sample Vale
Safety Valve(Breathing Valve),Water Seal Co2 Exhaust Valvee
Clamps And Gaskets, Pressure Gauge
Stainless Steel Legs With Stainless Leveling Footpads

1. Are you a factory or trader?

we are a factory.
2. How many kinds of machine do you have?
Our filing machine,water treatment equipment,labeling machine, have many models according to different function, we can customized for customer.
3.  How about the installation?
We will arrange technical people to your country and help you install machine and teach you how to operate machine. But the seller will pay for ticket, visa, salary and accommodation
4. How about the electricity?
Three phase, 220V,. We also can be customized according to customer.

1. What about machine power?

Different machine has different power, it usually is 10-20kw.
6,Is your machine easy broken?
Our machine will be tested before shipment, if you operate it carefully, you can use this machine more than ten years.
7.What is the easy-broken part?
We will make a list about it and some accessories that suggest you buy.
8.How long it will take for installation?
We have a set of standard installation process, it can be finished base on customer prepare everything.
9.How you solve machine problem or broken?
We sill provide assistant by wechat, whatsapp or telephone to find the problem, if customer can't solve it by themselves, we will send technical to help.
10.What's your payment term?
We adopt TT,LC
11.What's the delivery time?
Different model has different delivery time, but 30 days is enough for most model.
12. Is it ok for us to visit your factory to see machine running?
We welcome you to visit our factory any time. If you need, we can make samples that you need.
13.Is it ok for you to design and customize machine for us ?
Of course. We not only make standard model, but also make customized model.
14.How long is your warranty period?
We have one year guarantee except improper operation by buyer.
15.What ancillary equipment do we have for your machine?
We will make a list for you after you take a order from us about what machine you need to buy extra, such as air compressor and three phase electricity. You can buy them by yourselves or we buy them for you.
16.What's the package for machine?
We use wooden foot and pp film package, we can provide fumigation wooden box if you need.
17. How about transportation?
NINGBO port is near us, so we quote as FOB NINGBO.
18.How we get to your factory?You can transfer by Guangzhou, Beijing or Shanghai to Wenzhou airport. Guangzhou/Beijing to Wenzhou airport will take about 2 hours, Shanghai to Wenzhou airport will take about one hour. When you arrive at Wenzhou airport, we will arrange driver to pick up u.

19.Do you have agent in other country?
We have agents in more than 20 countries. We can search for you after you tell us which country you are.
20.Is it English for your operator interface?
Yes, we have English and Chinese for all our machine.
21.What certification do you have?
Our machine get CE certification
22. How many people do i need for your machine?
Our machine is fully automatic. You only need one people after machine running.
23.Why choose us
 1. Reasonable structure and refined parts make our machine reliable in use and more stability, that can improve your efficiency and reduce the maintenance costs
2.High quality plus circumspect after-sales service and technology supporting could make you rest easy, we offer 24/7 technical support to all customer and promise every standard fitting and be send within 24hours
