• Model NO.：ZQC-500
• Product Name：China Manufacturer Automatic Industrial Steam Coo
• Color：Silver
• Size：1500*1450*1600mm
• Weight：780kg
• Keywords：Steam Cooking Mixer Machine
• Power：3kw~5.5kw
• Materials：SUS304
• Capacity：50-600kg
• Heating Source：Stam,Gas,Electric
• Raw Materials：Vegetable, Fruit,Corns
• Transport Package：Woodern Case
• Specification：50-650L
• Trademark：Longze
• Origin：Shandong
• Production Capacity：500

Basic Info.

Model NO. ZQC-500 Product Name China Manufacturer Automatic Industrial Steam Coo Color Silver Size 1500*1450*1600mm Weight 780kg Keywords Steam Cooking Mixer Machine Power 3kw~5.5kw Materials SUS304 Capacity 50-600kg Heating Source Stam,Gas,Electric Raw Materials Vegetable, Fruit,Corns Transport Package Woodern Case Specification 50-650L Trademark Longze Origin Shandong Production Capacity 500

Product Description

Product Description
The steam cooking mixer machine is the ideal cooker for  all types of sauces and fruit jams. Cooking temperature can be adjusted as required .hemispherical bottom and automatic mixing system ensure perfect mixer of the product during cooking . German Siemens control screen can be added at the same time more than a dozen formulations, to meet the different needs of customers. Fully automatic design, fast and efficient, one person can operate several machines at the same time, saving time and labor costs.


Main Features
We offer customized services for different customers, differnt capacity form 50L to 650L,you can choose what you want .And according to differnt cooking materials we provide different heating methods, gas heating ,electric heating, steam heating ,thermal oil heating etc.
Wireless temperaute control monitors tempature continuous,precious temperature control to avoil over burnt ,prevent nutrient lost.
How to opetate?All of things done well on the control panel,environmentally friendly and safer operation.


More Details

All of machines used famous brand gear motor reducer, silent mode, no need maintenance , sealed mixing head to prevent from corrosion and no need maintenance .Stable without body shaking while in operation, but movable with heavy duty casters.
Water tap equipped for easy cleaning of the bowl,help you save time .Durable quality for continuous working 24/7,12 months warranty & lifetime maintenance free of charge,so if you have any questions you can contact me feel free.

Technical Parameters

Product Description	Steam cooking mixer machine
Bowl size	50L~650L, 700mm~1200mm dia., 5mm thickness; SUS304
Voltage	380V/3Ph/50Hz or as customized
Power	3Kw~5.5Kw
Capacity	50kg-350Kg per batch
Steel grade	All stainless SUS304
Automation	Full automatic
Heating source	Steam
Working pressure	0.3~0.6MPa
Max. temperature	160ºC
Temperature control	Wireless temp. sensor devices
Mixing style	Planetary mixing to avoid burnt
Mixing speed	Variable & adjustable
Accessories	Safety relief valve, pressure gauge, blow-down valve, condensed water auto drain valve,...
Applications	Universal to cook and mix all kinds of thick and sticky food materials, like spices & sauces, jam, paste, confectionery, nuts, sweets, fillings, vegetables,...

Applications
This machine widely used in candy, pharmacy, dairy products, alcohol, cakes, candied fruit, beverage, canned, braised food such as food processing, can also be used in large restaurant or dining room to boil soup, cook, stew, boil conger, etc., is a food processing to improve quality, shorten time, improve the working conditions.




Customer Visiting
All customers are welcome to visit our factory to witness the good quality of our machines in our showroom. Our showroom is full of newly manufactured machines for our customers witness testing and we are glad to provide all necessary materials for such testing.

Advanced Manufacturing Machinery
To increase our productivity for tight manufacturing schedule, we resort to bring in more advanced equipments, such, laser machines, NC machines, etc for standardization and modernization. We have employees with rich experience to solve any technical problems.

Shipping&Delivery
We have special team for packaging and delivery with close coordination with our warehouse for shipment. Wooden packaging material is strictly in accordance with international standard. We have our own trucks, forklifts to ensure shipment on schedule.
