• Model NO.：GGXQ2500A
• Weight：300 Kg
• Capacity：300-500kg,H
• Mesh Belt Width：800mm
• Transport Package：Wooden Packing
• Specification：2600*1400*1500mm
• Trademark：Gelgoog
• Origin：China
• HS Code：8433609000
• Production Capacity：200 Set,Sets Per Year

Basic Info.

Model NO. GGXQ2500A Weight 300 Kg Capacity 300-500kg/H Mesh Belt Width 800mm Transport Package Wooden Packing Specification 2600*1400*1500mm Trademark Gelgoog Origin China HS Code 8433609000 Production Capacity 200 Set/Sets Per Year

Product Description

Application of Air Bubble Fruit and Vegetable Washing Machine
The bubble cleaning machine is designed for materials with high requirements on appearance. It is suitable for cleaning and soaking granular, leafy, and rhizome products such as vegetables, fruits, aquatic products, and Chinese herbal medicines. The product is specially used for cleaning all kinds of fruits. Such as: strawberries, apples, etc., after the three cleaning methods of bubbling, surfing and spraying, they enter the brush for the second cleaning, so that the fruit is washed more cleanly and more thoroughly.

The bubble cleaning machine is suitable for cleaning mushrooms, celery, spinach, cabbage and other stem and leaf vegetables as well as apples, tomatoes, peppers, eggplants, cucumbers, and other fruits and vegetables. The professional vegetable cleaning machine uses water treatment technology. The bubble vegetable cleaning machine recycles the cleaning water. Save 80% of cleaning water.

Air Bubble Vegetable Washing Equipment Features
1. The cleaning process is automatically controlled by the computer, and it can be easily done with a finger move.
2. The bubble vegetable washing machine adopts vortex spray water flow to wash more thoroughly.
3. The washing machine uses high-pressure water to impact the surface of the object to be cleaned to form a cleaning water column containing bubbles. The high-speed movement of the cleaning water column impacts the surface of the object to be washed. A function of impact and scrubbing, the small bubble cleaning machine scrubs the surface of the object to be cleaned, and cleans the object to be cleaned.
4. The vegetable bubble cleaning machine cleans and cuts the stems, leaves, stems, etc., and walks in the high-pressure, tumbling bubbles, and the high-pressure water spray, cooling and aeration pumps are sprayed and rolled from the bottom of the spray barrel through the pipes and pipe holes. The bubble achieves the purpose of disinfection and cleaning.

Working Principle Of Air Bubble Vegetable Washing Machine
When the material falls into the water, the churning water in the tank is used to stir and clean the material. After the heavy dirt such as sand and sand on the material is separated, it falls into the sedimentation area under the filter screen. The material is gradually moved to the conveying network under the push of water. The belt is lifted out of the inner tank, and after spray cleaning, the material is washed for the second time, and then enters the following process. The washed rinsing material is intercepted by the filter. During the working process, the water inlet pipe and sprinkler pipe always supply water, so that the sewage in the water tank is gradually replaced.

Technical Parameter of Air Bubble Vegetable Washing Machine

Model	GGXQ2500A	GGXQ3000A	XQ4000	XQ5000
Power	Bubble: 2.2kw Mesh Belt: 0.75kw Water pump: 1.5kw	Bubble: 2.2kw Mesh Belt: 0.75kw Water pump: 1.5kw	Bubble: 4kw Mesh Belt: 1.1kw Water pump: 1.5kw	Bubble: 5.5kw Mesh Belt: 1.5kw Water pump: 2.2kw
Size	2600*1400*1500mm	3100*1400*1500mm	4100*1400*1500mm	5100*1400*1500mm
Weight	300 kg	500 kg	700kg	900kg
Mesh Belt Width	800mm	800mm	800mm	800mm
Capacity	300-500kg/h	500-1000kg/h	1000kg/h	1500kg/h
