• Model NO.：LH-H Series
• Application：Milk, Yogurt, Cheese
• Customized：Customized
• Working Pressure：20-100MPa
• Material：SS304 or SS316L
• Power：380V,3,50Hz, 220V,3,60Hz
• Parts：Abrasion Proof, Corrosion Proof
• Plunger：Stainless Steel, Chrome-Plated Steel,etc
• Transport Package：Wooden Package, Fix in Container, etc
• Specification：100-12000L,H
• Trademark：LIHONG
• Origin：China
• HS Code：84342000
• Production Capacity：5000PCS,Year

Basic Info.

Model NO. LH-H Series Application Milk, Yogurt, Cheese Customized Customized Working Pressure 20-100MPa Material SS304 or SS316L Power 380V/3/50Hz, 220V/3/60Hz Parts Abrasion Proof, Corrosion Proof Plunger Stainless Steel, Chrome-Plated Steel,etc Transport Package Wooden Package, Fix in Container, etc Specification 100-12000L/H Trademark LIHONG Origin China HS Code 84342000 Production Capacity 5000PCS/Year

Product Description

GJJ High-pressure Homogenizer

APP: For Dairy, Fruit juice, Drink, Syrup, Cosmetic
Flow Capacity: 0.2T/h-12T/h
Pressure Range:  25Mpa, 32MPa, 40Mpa, 60Mpa,
Material: SUS304 or SUS316L(Original SS quality certificate)

GJJ model series high pressure homogenizer is a kind of new product developed by us according to worldwide up to date technology. It is applied to the homogenization and emulsification of liquid material(liquid-liquid phase or liquid-solid phase) with viscosity below 0.2Pa.s and temperature lower than 80 degree. These materials include dairy food, beverage, cosmetics, medicine and so on.
  In time of operation, this product conveys processed material to homogenizing valve in a high pressure way by means of triple plunger reciprocating pump, to make the material acted upon by composite force like turbulent flow, positive hole and shearing at the moment when it flows by the small gap between valve disc and valve seat, thus achieving the goal of homogenization and emulsification.
High pressure homogenization has following excellent feature


1. Better stability
2. Improve preservation quality
3. Improve homogeneousness
4. Better absorption quality
5. Save expensive additive agent
6. Change viscosity
7. Reduce reaction time
8. Applicable to the cell cutting.

Adopting abrasion proof, corrosion and high temperature resistant tungsten-chrome-cobalt alloy purpose-made valve




With homogenizing head furnished with diamond on the top and special abrasion proof homogenizing device of valve set




3-cylinder" valve chamber

Plunger piston materials available for selection include solid stainless steel, chrome-plating steel, spray-painting alloy and ceramic



Model	Capacity (L/H)	Max pressure (MPa)	Rated Max pressure(MPa)	Motor power (kw)	Dimension (mm)
GJJ-0.2/25	200	25	20	2.2	755 x 520 x 935
GJJ-0.3/25	300	25	20	3	755 x 520 x 935
GJJ-0.5/25	500	25	20	4	1010 x 616 x 975
GJJ-0.8/25	800	25	20	5.5	1020 x 676 x 1065
GJJ-1/25	1000	25	20	7.5	1100 x 676 x 1065
GJJ-1.5/25	1500	25	20	11	1100 x 770 x 1100
GJJ-2/25	2000	25	20	15	1410 x 850 x 1190
GJJ-2.5/25	2500	25	20	18.5	1410 x 850 x 1190
GJJ-3/25	3000	25	20	22	1410 x 960 x 1280
GJJ-4/25	4000	25	20	30	1550 x 1050 x 1380
GJJ-5/25	5000	25	20	37	1605 x 1200 x 1585
GJJ-6/25	6000	25	20	43	1671 x 1260 x 1420
GJJ-8/25	8000	25	20	55	1671 x 1260 x 1420
GJJ-10/25	10000	25	20	75	2725 x 1398 x 1320
GJJ-12/25	12000	25	20	90	2825 x 1500 x 1320
GJJ-0.3/32	300	32	25	4	1010 x 616 x 975
GJJ-0.5/32	500	32	25	5.5	1020 x 676 x 1065
GJJ-0.8/32	800	32	25	7.5	1100 x 676 x 1065
GJJ-1/32	1000	32	25	11	1100 x 770 x 1100
GJJ-1.5/32	1500	32	25	15	1410 x 850 x 1190
GJJ-2/32	2000	32	25	18.5	1410 x 850 x 1190
GJJ-2.5/32	2500	32	25	22	1410 x 960 x 1280
GJJ-3/32	3000	32	25	30	1550 x 1050 x 1380
GJJ-4/32	4000	32	25	37	1605 x 1200 x 1585
GJJ-5/32	5000	32	25	45	1605 x 1200 x 1585
GJJ-6/32	6000	32	25	55	1671 x 1260 x 1420
GJJ-8/32	8000	32	25	75	2725 x 1398 x 1320
GJJ-0.1/40	100	40	35	3	755 x 520 x 935
GJJ-0.3/40	300	40	35	5.5	1020 x 676 x 1065
GJJ-0.5/40	500	40	35	7.5	1100 x 676 x 1065
GJJ-0.8/40	800	40	35	11	1100 x 770 x 1100
GJJ-1/40	1000	40	35	15	1410 x 850 x 1190
GJJ-1.5/40	1500	40	35	22	1410 x 960 x 1280
GJJ-2/40	2000	40	35	30	1550 x 1050 x 1380
GJJ-2.5/40	2500	40	35	37	1605 x 1200 x 1585
GJJ-3/40	3000	40	35	45	1671 x 1260 x 1420
GJJ-4/40	4000	40	35	55	1671 x 1260 x 1420
GJJ-5/40	5000	40	35	75	2725 x 1398 x 1320
GJJ-6/40	6000	40	35	90	2825 x 1500 x 1320
GJJ-0.1/60	100	60	50	4	1010 x 616 x 975
GJJ-0.2/60	200	60	50	5.5	1020 x 676 x 1065
GJJ-0.3/60	300	60	50	7.5	1100 x 676 x 1065
GJJ-0.5/60	500	60	50	11	1100 x 770 x 1100
GJJ-0.8/60	800	60	50	18.5	1410 x 850 x 1190
GJJ-1/60	1000	60	50	22	1410 x 960 x 1280
GJJ-1.5/60	1500	60	50	37	1605 x 1200 x 1585
GJJ-2/60	2000	60	50	45	2000 x 1300 x 1585
GJJ-2.5/60	2500	60	50	55	2000 x 1300 x 1585
GJJ-3/60	3000	60	50	75	2725 x 1398 x 1320
GJJ-4/60	4000	60	50	90	2825 x 1500 x 1320
GJJ-5/60	5000	60	50	110	2825 x 1500 x 1320
GJJ-0.1/70	100	70	60	5.5	1020 x 676 x 1065
GJJ-0.2/70	200	70	60	7.5	1100 x 676 x 1065
GJJ-0.3/70	300	70	60	11	1100 x 770 x 1100
GJJ-0.5/70	500	70	60	15	1410 x 850 x 1190
GJJ-1/70	1000	70	60	22	1410 x 960 x 1280
GJJ-1.5/70	1500	70	60	37	1605 x 1200 x 1585
GJJ-2/70	2000	70	60	45	2000 x 1300 x 1585
GJJ-2.5/70	2500	70	60	55	2000 x 1300 x 1585
GJJ-3/70	3000	70	60	75	2725 x 1398 x 1320
GJJ-4/70	4000	70	60	90	2825 x 1500 x 1320
GJJ-5/70	5000	70	60	110	2825 x 1500 x 1320
GJJ-0.1/100	100	100	80	7.5	1100 x 676 x 1065
GJJ-0.2/100	200	100	80	11	1100 x 770 x 1100
GJJ-0.3/100	300	100	80	15	1410 x 850 x 1190
GJJ-0.5/100	500	100	80	18.5	1410 x 850 x 1190
GJJ-1/100	1000	100	80	37	1605 x 1200 x 1585
GJJ-2/100	2000	100	80	75	2725 x 1398 x 1320
GJJ-3/100	3000	100	80	110	2825 x 1500 x 1320

Warranty: One year after receiving equipment, offer life long after sale service.
Installation and commissioning: We can send professional engineer to install and commission the equipment.
Maintenance services: any malfunction happened, once you enquiry us, we will reply you within 24 hours except the special reasons.
Inspection:  the third party inspection company or yourself to inspect the products before shipment.
Documentation: User manual, Maintenance manual, Equipment test report, etc.
