• Model NO.：KQ-EM
• Type：Mixer
• Voltage：380V
• Customized：Customized
• Name：Electricity Mixing Jacketed Mixing Vessel Reaction
• Agitator Speed：36rpm, 48rpm, 960rpm,2900rpm
• Stainless Steel Degree：Stainless Steel 304,316
• Heating and Mixing Tank：for Heating and Mixing Liquid, Liquid and Powder
• Storage Tank：Aseptic Storage Tank with Manhole
• Surface Treatment：Polished
• Delivery：10 Days
• Packing：Wooden Box
• OEM：Yes
• Factory：Shanghai China
• MOQ：1set
• Warranty：One Year
• Motor：Siemens ,ABB,China Brand
• Speed Control：Adjustable
• Certificate：ISO ,SGS
• Transport Package：Standard Export Wooden Box
• Specification：ISO
• Trademark：KQ
• Origin：Shanghai China
• HS Code：8479820090
• Production Capacity：200L To30000L
• Package size per unit product：220.00cm * 220.00cm * 950.00cm
• Gross weight per unit product：4500.000kg

Basic Info.

Model NO. KQ-EM Type Mixer Voltage 380V Customized Customized Name Electricity Mixing Jacketed Mixing Vessel Reaction Agitator Speed 36rpm, 48rpm, 960rpm,2900rpm Stainless Steel Degree Stainless Steel 304/316 Heating and Mixing Tank for Heating and Mixing Liquid, Liquid and Powder Storage Tank Aseptic Storage Tank with Manhole Surface Treatment Polished Delivery 10 Days Packing Wooden Box OEM Yes Factory Shanghai China MOQ 1set Warranty One Year Motor Siemens /ABB/China Brand Speed Control Adjustable Certificate ISO ,SGS Transport Package Standard Export Wooden Box Specification ISO Trademark KQ Origin Shanghai China HS Code 8479820090 Production Capacity 200L To30000L

Packaging & Delivery

Package size per unit product 220.00cm * 220.00cm * 950.00cm Gross weight per unit product 4500.000kg

Product Description

Electricity Mixing Jacketed Mixing Vessel Reaction Cooking Tank  Factory

1

sugar mixing tank

TankCapacity(L)	200, SS304	300, SS304	500, SS304	1000,SS304
REV	36r/min	36r/min	36r/min	36r/min
Electric motor of the agitator	0.55KW,380v,50hz	0.75KW,380v,50hz	0.75KW,380v,50hz	1.1KW,380v,50hz
Heating Area(M2)	0.9	1.1	1.9	4.5
Material Input/output(DN MM)	38	38	38	50
OUTSIDE DEMENSION(L*W*H)MM	900*900*1600	1000*1000*1500	1100*1100*1700	1400*1400*1750
GROSS WEIGHT(KGS)	150	200	300	450

Material: Ss304
* Type: With Jacket and insulation
* Internal shell thickness: 3 mm
* Jacket thickness: 3 mm
*PU INSULATION WALL: 50MM
* Outer shell thickness: 1.5 mm
* Appearance: Ellipsoidal head top and down manhole and pipe will be as the picture you sent to us
* Accessories:
Electricity Mixing Jacketed Mixing Vessel Reaction Cooking Tank  Factory .
