High Quality Vegetable Oil Press Extruder for Sale Oil Press

Hebei Huipin Machinery Co., Ltd.

Application：All
Voltage：380V

Base Info

Model NO.：260
Appearance：Horizontal
Press Materials：Tea Seed
Press Series：Second
Condition：New
Customized：Customized
Transport Package：Nude
Specification：3800*2320*3800mm
Trademark：HP
Origin：China
HS Code：84792000
Production Capacity：2000
Package size per unit product：2800.00cm * 1250.00cm * 1800.00cm
Gross weight per unit product：8000.000kg

Description

Basic Info.

Model NO. 260 Appearance Horizontal Press Materials Tea Seed Press Series Second Condition New Customized Customized Transport Package Nude Specification 3800*2320*3800mm Trademark HP Origin China HS Code 84792000 Production Capacity 2000

Packaging & Delivery

Package size per unit product 2800.00cm * 1250.00cm * 1800.00cm Gross weight per unit product 8000.000kg

Product Description

High Quality Vegetable Oil Press Extruder for Sale Oil Press in Kenya

The machine is suitable for extracting corn germ, rapeseed, cottonseed, peanut, sunflower seeds and other plant oilseeds

Model performance Characteristics:

1.The machine axles, pressing bolt, pressing bar, gear, gear box and other major parts, are all made of high quality steel, then with special processing, high temperature resistant,good wear-resisting performance, high product quality and durable.

2.The barrel screw using light pressure, regular pressure, the pressure step by step and other advanced technology, low residual oil

3.The cake checking mechanism has patented design, easy and quick.

4.Extracting cage has the design of ear plate opening and closing, easy to assembly and maintain, reduce labor intensity.

5.Can be adapted to the high, medium and low temperature pressing.

YZY260 spiral oil press and 75 kw motor installed base figure

Main technical data:

1.production capacity: pressing 35-45 Ton/Day, prepressing 100-150 ton.

2.Using of steam pressure:3-4kg/cm³.

3.Agitation shaft rotation speed:41 revolutions/Min.

4.Pressing axle rotation speed:28-51 revolutions/Min.

5.Feeding axle rotation speed:85 revolutions/Min.

6.Steaming and frying temperature:60-110ºC.
