• Model NO.：AY600
• Transport Package：Wooden Case
• Origin：China
• Production Capacity：1 Set,Month

Basic Info.

Model NO. AY600 Transport Package Wooden Case Origin China Production Capacity 1 Set/Month

Product Description

MAIN FEATURES
1, PLC /computer process control available;
2, An LED touch panel for easy operating;
3, Optional (mass) flowing controlled by Frequency inverters;
4, In-line injection, dosing and pre-mixing techniques for the proportional addition of liquid(milk); Dosing pumps for the automatic injection of colors, flavors and acids
5, One set of extra chocolate paste injection system for making chocolate-central candies; "two/three-color striped depositing", " two /three-color double layers depositing", "central filling", "clear" hard candies, lollipop can be made.
6, Moulds can be made according to the candies samples provided by the customer. "

Processing folw

Raw material dissolving→Conveying→Filting→Storaging→Constant Syrup converying→Pre-heating→Micro-film vacuum cooking→Mixing with flavor and color→Depositing→Stick Inserting→ Cooling→De-moulding→ Conveying→Packing→Final products

Model

Model	GY-CD150	GY-CD300	GY-CD450	GY-CD600
Output(kg/h)	150	300	450	600
Max candy weight	6g	6g	6g	6g
Speed	55~65 n/min	55~65 n/min	55~65 n/min	55~65 n/min
Steam consumption Steam pressure	250kg/h, 0.5~0.8MPa	300kg/h, 0.5~0.8MPa	400kg/h, 0.5~0.8MPa	500kg/h, 0.5~0.8MPa
Compressed air consumption Compressed air pressure	0.2m3/min,  0.4~0.6MPa	0.2m3/min,  0.4~0.6MPa	0.25m3/min,  0.4~0.6MPa	0.25m3/min,  0.4~0.6MPa
Electric power needed	18kW/380V	27kW/380V	34kW/380V	42kW/380V
Total length(m)	15	17	17	20
Gross weight	3500kg	4000 kg	4500 kg	5000 kg
