Tunnel Freezer for Vegetable and Seafood

SHAOXING WALLEY FOOD MACHINERY CO., LTD.
  • Type：Freezer
  • Voltage：380V
  • Power：11kw
  • Customized：Customized
  • Size：9.3*3.3*2.2m
  • Freezing Temperature：-36+,-2°c

Base Info

  • Model NO.：SSD-W-300
  • Freezing Time：5-50min Adjustable
  • Input Temperature：+15°c
  • Output Temperature：-18°c
  • Cold Load：70kw
  • Transport Package：Standard Export Package
  • Specification：300kg,h
  • Trademark：Walley
  • Origin：China
  • HS Code：8418699090

Description

Model

SSD-W-300

SSD-W-500

SSD-W-750

SSD-W-1000

SSD-W-1500

Capacity (kg/h)

300

500

750

1000

1500

Cold load (kw)

70

110

140

180

270

Freezer length (m)

7

8

10

13

16

Overall dimension (m) (L×W×H)

9.3×3.3×2.2

10.3×3.3×2.2

12.3×3.7×2.2

13×3.7×2.2

18.3×4.3×2.2

Power required (kw)

11

12

15

22

32

Input material temperature (ºC)

+15

Output material temperature (ºC)

-18

T inside the freezer (ºC)

-36±2

Freezing time (min)

10~50 (Continually adjustable)

Coolant

R717/R22/R404a



Detailed Pictures

Tunnel Freezer for Vegetable and Seafood

Tunnel Freezer for Vegetable and Seafood
Tunnel Freezer for Vegetable and Seafood
Tunnel Freezer for Vegetable and Seafood
Tunnel Freezer for Vegetable and Seafood
