Pet Bottle Blowing Machine
Zhangjiagang Zhongzheng Import and Export Co., Ltd.- Warranty：12months
- Processing Material：Natural Ingredients
- Application：Dairy, Beverage
- Customized：Customized
- Certification：ISO9001
- Power Source：Electric
Base Info
- Model NO.：PL-CSS9-38
- Automatic Grade：Automatic
- Transport Package：Standard Export
- Trademark：ZHONGZHENG
- Origin：China
- HS Code：84773090
- Production Capacity：200sets,Year
Description
AIR RECOVERY SYSTEM → SAVE INVESTMENT OF LOW PRESSURE COMPRESSOR SYSTEM Specification:
Clamping force :60000 kg
Clamping stroke :130 mm
Stretching stroke :320 mm
Bottom Stroke :50 mm
Cavity pitch :80 mm
Number of cavity :9
2) CONTAINER
Max. container volume :0.7 liter(9-cavity)
Max. neck diameter :18-30 mm
Max. container diameter :70 mm
Max. container height :320 mm
Max. container volume :2.0 liter(5-cavity)
Max. neck diameter :18-30 mm
Max. container diameter :105 mm
Max. container height :320 mm
3) ELECTRICAL SYSTEM
Total power :49KW
Heating power :50~70%
4) AIR SYSTEM
Blowing pressure :35 kg/cm2
Air consuming :11000 L/min
5) CHILLED WATER
Operation Pressure :4 kg/cm2
Temperature :10-12ºC
Consuming :11400 kcal/hr.
Flow rate :60 ltr/min
6) COOLING WATER
Operation pressure :2-4 kg/cm2
Temperature :30ºC
Consuming :45000 kcal/hr.
Flow rate :150 ltr/min
7) Machine size:6,100 x1,800 x 2,600 mm (L x W x H)
Machine weight:8,000 kg
8) Production speed is 15000BPH 500ml water bottle (16g)
Blow mold 1set Aluminum Alloy 7075
- PL-CSS9-38 , Fully Electric PET Stretch Blow Moulding Machine. Including Feeding System (Preform Tank, Conveyor, Unscrambler) &Air Recovery System.
Clamping force :60000 kg
Clamping stroke :130 mm
Stretching stroke :320 mm
Bottom Stroke :50 mm
Cavity pitch :80 mm
Number of cavity :9
2) CONTAINER
Max. container volume :0.7 liter(9-cavity)
Max. neck diameter :18-30 mm
Max. container diameter :70 mm
Max. container height :320 mm
Max. container volume :2.0 liter(5-cavity)
Max. neck diameter :18-30 mm
Max. container diameter :105 mm
Max. container height :320 mm
3) ELECTRICAL SYSTEM
Total power :49KW
Heating power :50~70%
4) AIR SYSTEM
Blowing pressure :35 kg/cm2
Air consuming :11000 L/min
5) CHILLED WATER
Operation Pressure :4 kg/cm2
Temperature :10-12ºC
Consuming :11400 kcal/hr.
Flow rate :60 ltr/min
6) COOLING WATER
Operation pressure :2-4 kg/cm2
Temperature :30ºC
Consuming :45000 kcal/hr.
Flow rate :150 ltr/min
7) Machine size:6,100 x1,800 x 2,600 mm (L x W x H)
Machine weight:8,000 kg
8) Production speed is 15000BPH 500ml water bottle (16g)
Blow mold 1set Aluminum Alloy 7075
