• Model NO.：XE1250GS4
• HS Code：8462319000

Basic Info.

Model NO. XE1250GS4 HS Code 8462319000

Product Description

High Precision Silicon Steel Sheet Slitting Line

Application: This Line is used to decoil and divide the big silicon steel coils into small strip coils. It is the necessary high-precision slitting equipment of transformer manufacturer.

Construction: It consists of hydraulic decoiler, charge hoist, feeding device, high precision locked round cutter, tension unit, hydraulic recoiler, cantilever supporting device, discharge car, hydraulic pneumatic system and electrical control cabinet.

Features:
1. High speed decoiler with cantilever support, adopt ground recoiling to save the heavy labor of excavating a pit.
2. Slitter with locked round shear cutter, easy to change slitting size.
3. Tension unit adopts air chamber type of compaction, making sure the balanced tension at the difference thickness of the strips.
4. Our technical team adopts advanced horizontal transmission to solve the problems of recoil gear lubricating.



Item No.	XE1250GS4
Name	Silicon Steel Sheet Slitting Line
Slitting Material	Silicon Steel Sheet
Slitting Thickness	0.15~0.5mm
Slitting Width	1250mm
Max Coil Weight	8t
Max Coil Dia	Φ2000mm
Decoiling Expansion Range	Φ380-Φ450/Φ450-Φ520
Dia of Round Cutter Chief Axis	Φ120mm
Recoiling Expansion Dia	Φ508mm
Slitting Lines	20
Min Slitting Width	50mm
Slitting Linear Velocity	120m/min
S Tolerance	≤0.05mm
Slitting Side Burrs	≤0.02mm
Power	About 65kW
Occupation Area	12×6.2 m
