• Origin：China
• Trademark：Kgentlest
• Transport Package：Wood Safety Packing
• Model NO.：QXL - 1000
• HS Code：8438500000
• Production Capacity：5000 PCS Per Year

Basic Info.

Model NO. QXL - 1000 Transport Package Wood Safety Packing Trademark Kgentlest Origin China HS Code 8438500000 Production Capacity 5000 PCS Per Year

Product Description

Tunnel style washing machine
It is part of the workshop conveying combination and can be used separately. It is mainly used to clean boxes and other pallets for meat.
Automatic control, reliable quality, tunnel transport, internal high-pressure nozzle cleaning, convenient and fast.

Model: QXL - 1000

Specifications: Width: 1400 length: 6000 height: 1600 mm

Drive: hollow shaft worm gear reducer, 0.55KW, frequency conversion speed regulation

Sanitary pump: stainless steel pump body: 5.5kwX2

Flow rate: 45 m3 / h

Head: 38 meters

Water consumption: tap water: 0.4t /h (pressure: 1.6bar)

Steam heating: 60

Working platform height: 1000 mm

Input box specification: length 600* width 400* height 200 mm (frequency conversion adjustable)

Production capacity: 600 PCS/hour (adjustable)

Energy pipeline: water supply: DN25,1~2 bar

Power: 12KW

Material: main cover, water tank and other shell adopts 304 stainless steel plate 2mm

The pipe adopts 3mm high pressure explosion-proof industrial pipe

Include: frequency conversion drive triple protection device, ease the impact of equipment startup on equipment transmission system

2*11 groups of high-pressure flushing pipes are used to ensure the cleaning effect

Automatic temperature control device, automatic water temperature, to solve the problem of manual operation

Automatic water feeding device, ensure continuous operation, prevent water pump dry pumping damage water pump

Multiple dirt filter device, automatically filter the impurities generated by cleaning, prevent clogging pipeline

Automatic control of water and steam solenoid valve to prevent equipment failure caused by water temperature or lack of water
